Roller conveyor curve 45-degrees

Single curve

Roller conveyor curve 45-degrees
Roller conveyor curve 45-degrees
Roller conveyor curve 45-degrees
Roller conveyor curve 45-degrees
Roller conveyor curve 45-degrees
Roller conveyor curve 45-degrees
Roller conveyor curve 45-degrees
429.00 *Prices are exclusive of VAT
Article code464045000
Original Flowrack type PRO+

- 45° Roller conveyor curve
- Special 3-piece curve rollers
- Safely closed curve profile
- Pre-assembled
- Roller length 400 mm
- Roller pitch 92 mm

Detailed info roller conveyors:

Detailed info curve variants:
Description

Durable curve to easily adjust your roller conveyor to your lay-out.
With the 3-piece curve rollers, the box follows the curve easily.

This curve also has a unique locked and safe curve profile.
Pre-assembled delivery.

Dimensions & technique

All parts are made out of galvanized steel.
Curves are attached by H-stands (to each other and to the roller conveyors).

Roller length 400 mm (EL).
Roller pitch maximum 92 mm (heart to heart).
3-piece curver roller ø50 mm, stainless steel bearing balls, colour blue.
Solid 8 mm axle, galvanized.

11 rolls for each 45° curve, maximum roller weight capacity 15 kg/piece.
165 kg loading capacity per 45° curve.

Scope of delivery

1x 45° curve, pre-assembled.
2x coupling brackets (with bolts/nuts).

Still needed

Stands, roller conveyors and possibly end profiles.
